YL-H13/H14-U15/U16 High efficiency filter (ULPA)
Page view:

YL-H13/H14-U15/U16 High efficiency filter (ULPA)

●Knife edge type/liquid groove type, jelly glue seal, good sealing quality; ●Low initial resistance and light weight; ●The wind speed uniformity is good, the dust volume is large; ●The filter efficiency is high, the main collection is 0.5um, 0.3um, 0.1um particles.
没有此类产品
Product description
YL-H13/H14-U15/U16 High efficiency filter (ULPA)

●Knife edge type/liquid groove type, jelly glue seal, good sealing quality;
●Low initial resistance and light weight;
●The wind speed uniformity is good, the dust volume is large;
●The filter efficiency is high, the main collection is 0.5um, 0.3um, 0.1um particles.

Use and usage
●Fresh air conditioning system of clean room, end filter of air outlet of dust free workshop;
●The air purification equipment, such as the FFU, is filtered by the air purifier.
●The main filtration in the purification equipment, such as the high efficiency feeding port of the liquid trough;
●It is mainly used for filtering the end of clean rooms such as pharmaceutical, bio-medicine, hospital, food production and health care products.

Technical Index
Filtration level: H12/H13/H14(EN779)
Filtration efficiency: 99.9%、99.99%、99.999%(ASHRAE52.1-1992)
Moisture Resistance: (relative humidity) ≤100%RH
Filter Media: ≥0.5um/ ≥0.3um/ ≥0.1um particles
Replacement cycle: end resistance =500PA (officially recommended) or continue to use in a year
Temperature resistant: ≤100℃

Materials and properties
●Filter material: artificial fiber paper, ultra-fine glass fiber filter paper; ·
●seal glue: persistent jelly glue;
●External frame: aluminum alloy frame;
●Separation: hot melt adhesive: white paint net, stainless steel net.
●Advantages: precision, small volume filtering area, low resistance, easy to install, reliable and durable sealing, used for the end of the air outlet of clean room.

Technical parameters


size

The rated air flow (m³/h

Initial resistance of different wind speeds.((pa



Filtration efficiency (%

High H(mm

Wide W(mm

Thick T(mm

0.25m/s

0.5m/s

0.75m/s

450

450

90/93

500

120

220

240

H13—H14

99.99%-99.999%

610

610

90/93

1000

120

220

240

915

610

90/93

1500

120

220

240

U15—U16

99.999%-99.9999%

1220

610

90/93

2000

120

220

240

Note: Specifications can be customized according to on-site requirements;
