YL-H12/H13/H14 High temperature and high efficiency filter.
Page view:

YL-H12/H13/H14 High temperature and high efficiency filter.

●There is partition board, partition board is: aluminium foil paper; ●Low temperature: 250 ℃, 400 ℃ environment for long-term use; ●The wind speed uniformity is good, the dust volume is large; ●The filter efficiency is high, the main catch is 0.3um, 0.5um above the particles.
没有此类产品
Product description
YL-H12/H13/H14 High temperature and high efficiency filter.

●There is partition board, partition board is: aluminium foil paper;
●Low temperature: 250 ℃, 400 ℃ environment for long-term use;
●The wind speed uniformity is good, the dust volume is large;
●The filter efficiency is high, the main catch is 0.3um, 0.5um above the particles.

Use and usage
●Fresh air conditioning system of clean room, end filter of air outlet of dust free workshop;
●High fire protection requirements and ventilation system end filtration of high temperature environment;
●It is widely used in electronic, optical, semiconductor, coating, chemical, biological medicine, hospital, automobile industry and so .

Technical Index
Filtration level: H12/H13/H14(EN779)
Filtration efficiency: 99.9%、99.99%、99.999%(ASHRAE52.1-1992)
Moisture Resistance: (relative humidity) ≤100%RH
Filter Media: ≥0.5um/ ≥0.3um particles
Replacement cycle: end resistance =500PA (officially recommended) or continue to use in a year
Temperature resistant: ≤250℃/≤350℃/≤400℃

Materials and properties
●Filter material: high temperature ultra-fine glass fiber filter paper;
●Separate objects: aluminum foil corrugated.
●sealing rubber: down corning high temperature resistant sealant;
●Seal strip: high temperature sealing strip (red)
●Outside frame: galvanized frame, aluminum frame, stainless steel frame;
●Network: stainless steel mesh.
●Advantages: precision and efficiency, high temperature resistance, fire protection, generally used in clean area of high temperature equipment.
●Disadvantages: thick thickness, heavy weight, not conducive to installation;
And the routine has no net, easy to damage, the installation of attention to good protection measures.

Technical parameters


size

The rated air flow (m³/h

Initial resistance of different wind speeds.(pa

Filtration efficiency(%



High H(mm

Wide W(mm

Thick T(mm

0.25m/s

0.5m/s

0.75m/s

320

320

220

400

120

220

240



H12—H14

99.9%-99.999%

484

484

150

800

120

220

240

630

630

220

1500

120

220

240

610

610

292

2000

120

220

240

Remarks: specifications can be customized according to the requirements of the site; Regular thickness .
