YL-H12/H13/H14 No diaphragm efficient filter
Page view:

YL-H12/H13/H14 No diaphragm efficient filter

●No partition board, thickness (minimum thickness of 25mm); ●Low initial resistance and light weight; ●The wind speed uniformity is good, the dust volume is large; ●The filter efficiency is high, and the main trap is 0.3um particles.
没有此类产品
Product description
YL-H12/H13/H14 No diaphragm efficient filter

●No partition board, thickness (minimum thickness of 25mm);
●Low initial resistance and light weight;
●The wind speed uniformity is good, the dust volume is large;
●The filter efficiency is high, and the main trap is 0.3um particles.

Use and usage
●Fresh air conditioning system of clean room, end filter of air outlet of dust free workshop;
●The air purification equipment, such as the FFU, is filtered by the air purifier.
●The main filter in the purifying equipment such as the efficient air supply outlet;
●It is widely used in electronic, optical, semiconductor, coating, chemical, biological medicine, hospital, automobile industry and other fields. Commercial and household purifier terminal filtration.

Technical Index
Filtration level: H12/H13/H14(EN779)  Filtration efficiency: 99.9%、99.99%、99.999%(ASHRAE52.1-1992)
Moisture Resistance:(relative humidity) ≤100%RH    Filter Media:≥0.5um/ ≥0.3um particlesReplacement cycle:end resistance =500PA (officially recommended) or continue to use in ayear
Temperature resistant:≤100℃

Materials and properties
●Filter material: artificial fiber paper, ultra-fine glass fiber filter paper;
● Glue: double component AB glue;
●Separation: hot melt adhesive.
●sealing strip: foaming EVA.
●Outside frame: wooden frame, galvanized frame, aluminum frame, stainless steel frame, plastic frame;
●Network: white baking paint net, stainless steel mesh,
●Advantages: precision and high efficiency, small volume, large filtration area, low resistance, light, used for the end of the air supply outlet of the clean room, cleanliness of the end of the equipment.

Technical parameters


size

The rated air flow (m³/h

Initial resistance of different wind speeds.(pa

Filtration efficiency(%

High H(mm

Wide W(mm

Thick T(mm

0.25m/s

0.5m/s

0.75m/s

320

320

69

300

120

220

240





H12—H14

99.9%-99.999%

484

484

69

500

120

220

240

610

610

90

1500

120

220

240

630

630

90

1500

120

220

240

1170

570

69

1800

120

220

240

Remarks: specifications can be customized according to the requirements of the site; Regular thickness .
