YL-H12/H13/H14 diaphragm efficient filters.
Page view:

YL-H12/H13/H14 diaphragm efficient filters.

●A W type box-type structure; ●Low initial resistance, good air permeability; ●Large amount of dust, large air volume; ●The installation flange frame can be interchanged with the bag filter.
没有此类产品
Product description
YL-H12/H13/H14 diaphragm efficient filters.

●There is partition board technology, partition board is: corrugated paper, aluminum foil paper;
●Low initial resistance, good air permeability;
●The wind speed uniformity is good, the dust volume is large;
●The filter efficiency is high, the main catch is 0.3um, 0.5um above the particles.

Use and usage
●Clean room fresh air air-conditioning system, dust-free workshop outlet end filter;
●The main filtration in the purification equipment such as high efficient air outlet;
●Widely used in electronics, optics, semiconductors, painting, chemical, biomedical, hospital, automotive industry and other fields.

Technical Index
Filtration level: H12/H13/H14(EN779)
Filtration efficiency: 99.9%、99.99%、99.999%(ASHRAE52.1-1992)
Moisture Resistance: (relative humidity) ≤100%RH
Filter Media: ≥0.5um/ ≥0.3um particles
Replacement cycle: end resistance =500PA (officially recommended) or continue to use in a year
Temperature resistant:≤100℃

Materials and properties
●Filter material: artificial fiber paper, ultra-fine glass fiber filter paper;
●Sealing strip: foaming EVA.
●The separation: double offset paper corrugated, aluminum foil corrugated.
●Glue: double component AB glue;
●Network: white paint net, stainless steel mesh.
●Outside frame: wooden frame, galvanized frame, aluminum frame, stainless steel frame, plastic frame;
●Advantages: precision and high efficiency, often used in the end of the air supply end of clean room, purification equipment terminal.

Technical parameters


size

The rated air flow (m³/h

Initial resistance of different wind speeds.pa

iltration efficiency (%

High H(mm

Wide W(mm

Thick T(mm

0.25m/s

0.5m/s

0.75m/s

320

320

220

400

120

220

240



H12—H14

99.9%-99.999%

484

484

150

800

120

220

240

630

630

220

1500

120

220

240

610

610

292

2000

120

220

240

Remarks: specifications can be customized according to the requirements of the site; Regular thickness .
