YL-F9/H10/H11/H12 Densely pleated W - type
Page view:

YL-F9/H10/H11/H12 Densely pleated W - type

●A W type box-type structure; ●Low initial resistance, good air permeability; ●Large amount of dust, large air volume; ●The installation flange frame can be interchanged with the bag filter.
没有此类产品
Product description
YL-F9/H10/H11/H12 Densely pleated W - type

●A W type box-type structure;
●Low initial resistance, good air permeability;
●Large amount of dust, large air volume;
●The installation flange frame can be interchanged with the bag filter.

Use and usage
●Clean room new air conditioning system, dust - free workshop air flow middle or end filtration;
●The large air volume demand of the site, and the installation space of the small ventilation system filtering;
●It is widely used in electronic, optical, semiconductor, coating, chemical, biological medicine, hospital, automobile industry and so on.

Technical Index
Filtration level: H12/H13/H14(EN779)
Filtration efficiency: 99.9%、99.99%、99.999%(ASHRAE52.1-1992)
Moisture Resistance: (relative humidity) ≤100%RH
Filter Media: ≥0.5um/ ≥0.3um particles
Replacement cycle: end resistance =500PA (officially recommended) or continue to use a year
Temperature resistant: ≤100℃

Materials and properties
●Filter material: artificial fiber paper, ultra-fine glass fiber filter paper; Separator: hot melt adhesive.
●Glue: double component AB glue; Sealing strip: foaming EVA.
●Outside frame: black plastic frame, galvanized frame, aluminum frame, stainless steel frame;
●Features: low resistance and high efficiency, the v-type design increases the gas flow, the ventilation volume is large, and can be interchanged with the bag filter.

Technical parameters




Type/model

size

Area of the filter material   (m²)

The rated air flow (m³/h

Separating surface

Filter rating (En779

Filtration efficiency (%

High H(mm

Wide W(mm

Thick T(mm

YL-MZS  FV Single flange

592

592

292

20.81

3400

4 lattices and 8sides





F9-H12





90%-99.9%

592

287

292

10.40

1700

YL-MZS  HV box type

610

610

292

18.26

3400

5 lattices and 10 sides

305

610

292

8.06

1700

Note: the above is the industry standard size, generally not customized.
